Brass Wing Nuts are threaded nuts with wings on opposite sides of the body intended for manual turning. Commonly used in applications where the fastener is often adjusted or frequently removed.
| TECHNICAL SPECIFICATIONS | ||
|---|---|---|
| Material | Brass | |
| Thread | Coarse | |
| Type | Threaded type Wing Nut | |
| Size | 1/4" | |
| Grade | Free Cutting Brass, CDA 360 Brass, C360 Brass | |
| Brass Wing Nut |
• BS 3692 • BS 57 • IS/1363 • IS/1367 |
|
| d1 | d2 | e | g | h |
|---|---|---|---|---|
| M4 | 6 | 18 | 1.7 | 8.5 |
| M5 | 8 | 24 | 2.3 | 11 |
| M6 | 10 | 30 | 2.7 | 15 |
| M8 | 13 | 36 | 3.6 | 18 |
| M10 | 17 | 48 | 4.6 | 23 |
| M12 | 20 | 62 | 5.6 | 31 |
| M16 | 26 | 70 | 6.5 | 35 |
| M20 | 32 | 86 | 7 | 44 |
| M24 | 41 | 106 | 8.6 | 53.5 |
