The Sleeve Anchor is constructed of high quality steel parts. Each part is zinc plated and assembled into a complete ready-to-use anchor. The anchor consists of a threaded stud with an outwardly flared cone-shaped end. A tubular expander sleeve is assembled over the stud and butted against the small diameter of the cone.
| TECHNICAL SPECIFICATIONS | ||
|---|---|---|
| Thread | Internally Threaded, Slotted | |
| Type | Round | |
| Drive Type | Round | |
| Grade | A1 & A2 Stainless Steel, A2 & A4 Steel | |
| Material | Steel, Stainless Steel, Brass, Other light alloy | |
| Applications | Light to medium-duty into concrete, brick and block. | |
| Anchor Dia. | Hole Size | Bolt Dia. | Min. Embed. | Fixture Hole Dia. | Wrench Size*** | Reqd. Torque |
|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 3/16" | 1-1/8" | 5/16" | 3/8" | 5 ft/lb |
| 5/16" | 5/16" | 1/4" | 1-7/16" | 3/8" | 7/16" | 8 ft/lb |
| 3/8" | 3/8" | 5/16" | 1-1/2" | 7/16" | 1/2" | 15 ft/lb |
| 1/2" | 1/2" | 3/8" | 2-1/4" | 9/16" | 9/16" | 25 ft/lb |
| 5/8" | 5/8" | 1/2" | 2-3/4" | 11/16" | 3/4" | 50 ft/lb |
| 3/4" | 3/4" | 5/8" | 3-3/8" | 13/16" | 15/16" | 90 ft/lb |
