Round Studs have high tensile strength and can sustain bulkier loads as compared to other studs. Round Types of Studs are used for supporting Insulation in the Industrial furnaces. Square Washers are used for Locking these type of studs.
TECHNICAL SPECIFICATIONS | ||
---|---|---|
Thread Type | Internally Threaded | |
Type | Round | |
Drive Type | Round | |
Grade | A1 & A2 Stainless Steel, A2 & A4 Steel | |
Material | Steel, Stainless Steel, Brass, Other light alloy | |
Applications | Used for all light and medium duty fixing in Building Industry. |
Thread Size | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 |
---|---|---|---|---|---|---|---|---|---|
Outside (Mm) | 5 | 6.5 | 8 | 8 | 10 | 12 | 15 | 18 | 20 |
Full Length (Mm)15 | 15 | 20 | 23 | 28 | 28 | 32 | 38 | 43 | 50 |
Safe Static Load Tension (KN) | 0.02 | 0.87 | 1.10 | 1.30 | 1.40 | 2.20 | 2.30 | 2.50 | 2.85 |
