| TECHNICAL SPECIFICATIONS | ||||
|---|---|---|---|---|
| Size | 16mm to 90mm & J4" to 3'/i" | |||
| Standard | BS 6121: Part-1:2005, EN 50262:1999, IEC62444:2010 | |||
| Function | Providing environmental seal on the cable outer sheath. Also provides mechanical cable retention & electrical continuity via armoured wire termination in indoor and outdoor area with all types of SWA cable. | |||
| Ingress Protection | IP66 | |||
| Material | Brass CW614N, Stainless Steel 316L | |||
| Thread | Metric, NPT | |||
| Operating Temp. | -20°C to +80°C | |||
| Cable Type | Wire Braid Armour, Screened Flexible Wire Braid (CY/SY), Pliable Wire Armour (PWA), Steel Tape Armour (STA), Aluminium Strip Armour (ASA) | |||
| Seal Material | Neoprene | |||
| Features | Armoured Ring | |||
| Accessories | PVC Shroud, Earth Tag, Serrated Washer and Entry Thread Seal | |||
