| TECHNICAL SPECIFICATIONS | |||||||
|---|---|---|---|---|---|---|---|
| Size | G204 to G755 | ||||||
| Standard | BS 6121: Part-1:2005, EN 50262:1999, IEC62444:2010 | ||||||
| Function | Provides mechanical cable retention & electrical continuity via armoured wire termination in dry indoor area for all types of SWA cables. | ||||||
| Ingress Protection | IP2X | ||||||
| Material | Brass CW614N, Stainless Steel 316L | ||||||
| Thread | Metric | ||||||
| Operating Temp. | -60eC to +200*C | ||||||
| Cable Type | Single Wire Armour (SWA) Cable | ||||||
| Features | Armoured Ring | ||||||
| Accessories | PVC Shroud and Earth Tag | ||||||
